[All Nodes]
nodes = 481480,481481,481482,1399,1398
menu = yes
system = Nodes

[481480]
host = 192.168.21.240:5038
user = admin
passwd = "XXXX"
menu = yes
hideNodeURL = no
system = Nodes

[481481]
host = 192.168.21.241:5038
user = admin
passwd = "XXXX"
menu = yes
hideNodeURL = no
system = Nodes

[481482]
host = 192.168.21.242:5038
user = admin
passwd = "XXXX"
menu = yes
hideNodeURL = no
system = Nodes

[1399]
host = 192.168.21.241:5038
user = admin
passwd = "XXXX"
menu = yes
hideNodeURL = yes
system = Nodes

[1398]
host = 192.168.21.242:5038
user = admin
passwd = "XXXX"
menu = yes
hideNodeURL = yes
system = Nodes

[lsNodes 481480]
url = "http://gm4slv.plus.com:42110/cgi-bin/lsnodes_web?node=481480"
menu = yes
system = LsNodes

[lsNodes 481481]
url = "http://gm4slv.plus.com:42111/cgi-bin/lsnodes_web?node=481481"
menu = yes
system = LsNodes

[lsNodes 481482]
url = "http://gm4slv.plus.com:42112/cgi-bin/lsnodes_web?node=481482"
menu = yes
system = LsNodes

[Node 481840]
url = "http://gm4slv.plus.com:42110/"
menu = yes
system = Dashboards

[Node 481841]
url = "http://gm4slv.plus.com:42111/"
menu = yes
system = Dashboards

[Node 481842]
url = "http://gm4slv.plus.com:42112/"
menu = yes
system = Dashboards

[GM4SLV Wiki]
url = "https://gm4slv.org.uk/dokuwiki/doku.php?id=start"
menu = yes
system = External Sites

[Echolink Link Status]
url = "https://echolink.org/links.jsp?d=1&gs=IP90gg&sel=gridsq"
menu = yes
system = External Sites

[TGIF]
url = "https://tgif.network/"
menu = yes
system = External Sites

[AllStarLink]
url = "http://www.allstarlink.org"
menu = yes
system = External Sites

#!/bin/bash
#
#  Created by Marshall Dias
#  Modified by Doug, WA3DSP 8/18/2015
#
# using ULAW format
#
# Script to write Calls to /var/lib/asterisk/sounds/rpt/nodenames
# which will then be used in place of node numbers. This script
# will NOT overwrite exisitng files unless you use the -o option.
# If you want to start clean and delete all nodename files do
#    rm -rf /var/lib/asterisk/sounds/rpt/nodenames/*
# or delete just the files you want to replace.
#
# A single node number can be specified on the command line with
# the -n node -ex. -n 40000
#
# A -v option gives a little more info

# See all comments below

# Set the source directory to the Allstar database on your system.
# 'locate astdb.php'  This file will exist if you are running any of the
# images from hamvoip.org or you have installed allmon or lsnodes on
# your system. For the BBB and RPi2 it will generally be /var/log/asterisk

SRCDIR=/var/log/asterisk
#SRCDIR=/var/www/html/allmon

# Set the destination directory.
# Use a tmp directory for testing
# The final destination for Allstar would be
# /var/lib/asterisk/sounds/rpt/nodenames
# Use the -d path option to overide

DESTDIR=/var/lib/asterisk/sounds/rpt/nodenames
# Test destination directory - must exist
#DESTDIR=/tmp/nodes

# Definitions of sound file directories

NODENAMES=/var/lib/asterisk/sounds/rpt/nodenames
LETTERS=/var/lib/asterisk/sounds/letters
NUMBERS=/var/lib/asterisk/sounds/digits
STRING=""

usage()
{
cat << EOF

Usage: $0 options

Writes voice files of call signs from node numbers

OPTIONS:
   -h        Show this message
   -o        Overwrite existings file(s)
   -n node   Specify node number - single write
   -d path   Specify path to output files
             Default: /var/lib/asterisk/sounds/rpt/nodenames
   -v        Verbose

Write callsign for node 40000, no overwrite -

  $0 -n 40000

Write callsign for node 40000, overwrite -

  $0 -on 40000

Write all callsigns, no overwrite -

  $0

Write all callsigns, overwrite

  $0 -o

Write single node to specific directory -

  $0 -n 40000 -d /etc/asterisk/local


EOF
}

OVERWRITE=""
VERBOSE=""

while getopts "hovn:d:" OPTION
do
     case $OPTION in
         h)
             usage
             exit 1
             ;;
         d)
             DESTDIR=$OPTARG
             ;;
         o)
             OVERWRITE=1
             ;;
         n)
             node=$OPTARG
             ;;
         v)
             VERBOSE=1
             ;;
         ?)
             usage
             exit
             ;;
     esac
done

# Form filenames from callsign
make_call ()
{
 STRING=""
 foo=${f2,,}
 for (( i=0; i<${#foo}; i++ )); do
  char=${foo:$i:1}

                case ${foo:$i:1} in
                [0-9]*) FILENAME=$NUMBERS/$char.ulaw ;;
                "/") FILENAME=$LETTERS/slash.ulaw ;;
                "-") FILENAME=$LETTERS/dash.ulaw ;;
                [a-z]*|[A-Z]*) FILENAME=$LETTERS/$char.ulaw ;;
                esac
STRING="$STRING $FILENAME"
done
}

# Concatenate filenames into final audio file
write_call ()
{
if [ ! $OVERWRITE ]
 then
   if [ -f "$DESTDIR/$f1.ulaw" ]
     then
        echo "$DESTDIR/$f1.ulaw exists - not overwriting"
        return
   fi
fi
echo "Writing $DESTDIR/$f1.ulaw"
cat $STRING > "$DESTDIR/$f1.ulaw"
}

# If no node given process all nodes
if [ -z "$node" ]
then
  while IFS='|' read f1 f2 f3 f4
  do
    if [ $VERBOSE ]; then echo "Processing Node Number: $f1 - Callsign: $f2" ; fi
    make_call
    write_call
  done < $SRCDIR/astdb.txt
else
# process just given node
  CALL=`grep -m 1 $node $SRCDIR/astdb.txt`
  if [ -z "$CALL" ]
    then
      echo "No Call found for node - $1"
      exit
    else
      f2=`echo $CALL | awk -F"|" '{print $2}'`
  fi
  f1=$node
  if [ $VERBOSE ]; then echo "Processing Node Number: $node - Callsign: $f2" ; fi
  make_call
  write_call
fi

# !/bin/bash
#
#  write_node_callsigns.sh v0.8
#
#  Doug, WA3DSP 8/18/2015
#  Portions by Marshall Dias
#
# Script to write Calls to /var/lib/asterisk/sounds/rpt/nodenames
# which will then be used in place of node numbers. This script
# will NOT overwrite exisitng files unless you use the -o option.
# If you want to start clean and delete all nodename files do
#    rm -rf /var/lib/asterisk/sounds/rpt/nodenames/*
# or delete just the files you want to replace.
#
# A single node number can be specified on the command line with
# the -n node -ex. -n 40000
#
# A -v option gives a little more info
#
# v 0.7 - removed level changing as this is accomplished in
#         global telemetry level parameters. Files should
#         stay at nominal levels.

# V 0.8 - added code to ignore semicolon comments.  6/5/2020, WA3DSP

# See all comments below

# Set the source directory to the Allstar database on your system.
# 'locate astdb.php'  This file will exist if you are running any of the
# images from hamvoip.org or you have installed allmon or lsnodes on
# your system. For the BBB and RPi2 it will generally be /var/log/asterisk

SRCDIR=/var/log/asterisk

# Set the destination directory.
# Use a tmp directory for testing
# The final destination for Allstar would be
# /var/lib/asterisk/sounds/rpt/nodenames
# Use the -d path option to overide

DESTDIR=/var/lib/asterisk/sounds/rpt/nodenames
# Test destination directory - must exist
#DESTDIR=/tmp/nodes

# Definitions of sound file directories

RPTSOUNDS=/var/lib/asterisk/sounds/rpt
NODENAMES=/var/lib/asterisk/sounds/rpt/nodenames
LETTERS=/var/lib/asterisk/sounds/letters
NUMBERS=/var/lib/asterisk/sounds/digits
STRING=""


usage()
{
cat << EOF

write_node_callsigns.sh v0.8
Usage: write_node_callsigns.sh options

Writes Asterisk Allstar voice files of call signs from node numbers

OPTIONS:

   -h        Show this message
   -a        Process all nodes
   -i        Include node number with call
   -o        Overwrite existing file(s)
   -n node   Process single node (overrides -a)
   -d path   Specify path to output files
             Default: /var/lib/asterisk/sounds/rpt/nodenames
   -v        Verbose

Write callsign for node 40000, no overwrite, all nodes -
    $0 -n 40000
Write callsign for node 40000, overwrite, all nodes -
    $0 -on 40000
Write all callsigns, no overwrite -
    $0 -a
Write all callsigns, overwrite
    $0 -ao
Write single node to specific directory -
    $0 -n 40000 -d /etc/asterisk/local
Write single node including both call and node number, overwrite
    $0 -ion 40000

EOF
}

OVERWRITE=""
VERBOSE=""
INCNODE=""
VOLUME=""

if [ $# -eq 0 ];
then
    usage
    exit 0
fi

if [ ! -e $SRCDIR/astdb.txt ]
then
  echo "$SRCDIR/astdb.txt not found - Be sure to point SRCDIR in script to file location."
  exit
fi

while getopts "hail:ovn:d:" OPTION
do
     case $OPTION in
         h)
             usage
             exit 1
             ;;
	 a)  ;;
	 d)
	     DESTDIR=$OPTARG
	     ;;
	 i)
	     INCNODE=1
	     ;;
         o)
	     OVERWRITE=1
             ;;
         n)
             node=$OPTARG
             ;;
         v)
             VERBOSE=1
             ;;
         ?)
             usage
             exit
             ;;
     esac
done

# Form filenames from callsign
make_call ()
{
 foo=${1,,}
 for (( i=0; i<${#foo}; i++ )); do
  char=${foo:$i:1}

                case ${foo:$i:1} in
                [0-9]*) FILENAME=$NUMBERS/$char.gsm ;;
                "/") FILENAME=$LETTERS/slash.gsm ;;
                "-") FILENAME=$LETTERS/dash.gsm ;;
                [a-z]*|[A-Z]*) FILENAME=$LETTERS/$char.gsm ;;
                esac
STRING="$STRING $FILENAME"
done
}

# Concatenate filenames into final audio file
write_call ()
{
if [ ! $OVERWRITE ]
 then
   if [ -f "$DESTDIR/$f1.gsm" ]
     then
        echo "$DESTDIR/$f1.gsm exists - not overwriting"
	return
   fi
fi

echo "Writing $DESTDIR/$f1.gsm"
    cat $STRING > $DESTDIR/$f1.gsm
}

# If no node given process all nodes
if [ -z "$node" ]
then
  Total=0
  while IFS='|' read f1 f2 f3 f4
  do
    if [[ $f1 =~ ^\; ]]; then continue ; fi
    if [ -z $f1 ]; then continue ; fi
    if [ $VERBOSE ]; then echo "Processing Node Number: $f1 - Callsign: $f2" ; fi
    ((Total=Total+1))
    STRING=""
    make_call $f2
# Test for including node number
   if [ $INCNODE ]
    then
     STRING=$STRING" $RPTSOUNDS/node.gsm "
     make_call $f1
    fi
    write_call
  done < $SRCDIR/astdb.txt
  echo -e "\nProcessed $Total Nodes\n"
else
# process just given node (-n node)
  CALL=`grep -m 1 $node $SRCDIR/astdb.txt`
  if [ -z "$CALL" ]
    then
      echo "No Call found for node - $1"
      exit
    else
      f2=`echo $CALL | awk -F"|" '{print $2}'`
  fi
  f1=$node
  if [ $VERBOSE ]; then echo "Processing Node Number: $node - Callsign: $f2" ; fi
  STRING=""
  make_call $f2
# Test for including node number
  if [ $INCNODE ]
  then
    STRING=$STRING" $RPTSOUNDS/node.gsm "
    make_call $f1
  fi
  write_call
fi
